OMRON

Omron 12VDC Coil Volts, Latching Relay, 3A @ 240VAC/3A @ 24VDC Contact Rating, Square

Hover over image to magnify
Latching Relay,10 Pins,Square,
PI_Asset_1364887
Latching Relay,10 Pins,Square,
PI_Asset_1364887
Omron 12VDC Coil Volts, Latching Relay, 3A @ 240VAC/3A @ 24VDC Contact Rating, Square Video

#924844-2 | Pkg Qty: 1

$57.89 pkg | $57.89 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
AC Contact Rating
3 A @ 240 V
Number of Pins
10
Base Type
Square
Number of Poles
2
Body Depth
1.1 in.
Overall Height
1.67 in.
Body Height
1.42 in.
Package Quantity
1
Body Width
0.85 in.
Pins
10
Brand
OMRON
Plug-In Relay Style
Latching
Coil VA Rating
0.9
Push To Test
Manual
Coil Volts
12 VDC
Relay Power Consumption
0.9 W
Contact Form
DPDT
Resistive Contact Amp Rating
3
Contact Material
Silver Nickel
Response Time
15 msec
Contact Rating
3 A @ 220 VAC/24 VDC
Shipping Weight
.04 lb.
DC Contact Rating
3 A @ 24 V
Socket
Mfr. No. PYF14AE
Input Power Consumption
0.9 W
Socket Code
G
Item
Latching Relay
Status Indicator
No
Mfr. Part Number
MY2K-US-DC12
Type
Dual Coil Latching
Mounting
Plug In
General
AC Contact Rating - Relay
3A @ 240V
HP @ 240V
1/6 hp
Base Type - Plug In Relay
Square
Mounting - Relay
Plug In
Body Depth - Relay
1.1 in
Number of Pins - Relay
10
Body Height - Relay
1.42 in
Overall Height - Relay
1.67 in
Body Width - Relay
0.85 in
Power Consumption - Relay
0.9 W
Contact Form - Relay
DPDT
Socket Code - Relay
G
DC Contact Rating - Relay
3A @ 24V
Standards
UL508
HP @ 120V
1/6 hp

Product Description

Latching Relay, Coil Volts 12V DC, AC Contact Rating - Relay 3A @ 240V, DC Contact Rating - Relay 3A @ 24V, Base Type - Plug In Relay Square, Number of Pins - Relay 10, Contact Form - Relay DPDT, Mounting - Relay Plug In, Socket Code - Relay G, Power Consumption - Relay 0.9 W, Contact Material Silver Nickel, Status Indicator No, Push To Test Manual
