Home All Products Electrical Switches & Relays Industrial Switches Proximity Sensors & Switches SKU: 942561-9
Share
Print
New
IFM

Ifm Cordset: M12 Male Right Angle X M12 Female Straight, 5 Pins, Black, Pur, 2 Ft Cable Lg

Hover over image to magnify
Cordset,5 Pin,Receptacle,
Cordset,5 Pin,Receptacle,

#942561-9 | Pkg Qty: 1

$18.45 pkg | $18.45 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Brand
IFM
Item
Cordset
Cable Length
2 ft.
Maximum Amps
4 A
Connector Type
M12
Maximum Voltage
250VAC, 300VDC
End 1 Connection Type
M12
Mfr. Part Number
EVC015
End 1 Gender
Male
Package Quantity
1
End 1 Number of Pins
5
Shipping Weight
.07 lb.
End 1 Thread
M12
Temperature Range
-13 to 167deg. F
End 2 Connection Type
M12
Wire Size
22 AWG
IP Rating
IP65, IP67, IP68, IP69K
General
Cable Jacket Color
Black
End 2 Number of Pins
4
Cable Jacket Material
PUR
End 2 Thread
M12
Cordset Configuration
M12 Male Right Angle X M12 Female Straight
Features
Gold-Plated Contacts
Cordset Type
Double-Ended
Max. Amps
4 A
End 1 Mounting Orientation
Right Angle
Max. Voltage
250 V AC, 300 V DC
End 1 Number of Keyways
1
Maximum Operating Temperature
167 Degrees F
End 2 Gender
Female
Minimum Operating Temperature
-13 Degrees F
End 2 Mounting Orientation
Straight
Number of Wires
4
End 2 Number of Keyways
1
Standards
cRUus Approval

Product Description

This patch cable is designed with a lock-in-place coupling nut that secures the cordset to a quick disconnect sensor and resists high levels of shock and vibration. It features a mechanical end-stop insert which helps to prevent damage to the O-ring. It also features a high-flex, PUR-jacketed cable designed to resist oils, coolants, and harsh conditions in industrial automation. Silicon and halogen free.

Item Barcode
9425619
Cordset,5 Pin,Receptacle,
 NameItemDescription
Grainger DropshipGrainger Dropship35T491
UNSPSC CODESUNSPSC CODES26121607
VMRS (ATA) CODESVMRS (ATA) CODES053-006-009Cordset,5 Pin,
