LIQUIDYNAMICS INC.
Electric Operated Drum Pump: 1/10 hp Motor HP, 8 gpm Max. Flow Rate, 110V AC, 4.5
Hover over image to magnify
Purchase with required items below
#939495-8 | Pkg Qty: 1
$3,478.65 pkg | $3,478.65 ea
Pricing is subject to change without notice
Drop Ship Item
Shipping to 60045
Required Items
Items below are required. They are not included and need to be ordered separately.
Technical Specifications
Key Specifications
Brand
LIQUIDYNAMICS INC.
Pack Quantity
1
Mfr. Part Number
DR15R50TASXXRSV
Shipping Weight
161 lb.
General
Compatible Chemicals
Acetic Acid 20%, Ammonium Hydroxide, Antifreeze (Coolant), Citric Acid 50%, DEF, Deionized Water, Ethyl (Ethanol), Ethylene Glycol, Formaldehyde, Formaldehyde 40%, Fresh Water, Glycerin, Isopropyl (Isopropanol), Potassium Hydroxide (50%), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfite, Sodium Hypochlorite/Bleach (to 20%)
Max. Fluid Temp.
104 Degrees F
Diesel Exhaust Fluid Compatible
Yes
Max. Head - Pumps
48 ft
Discharge Connection Type
Hose Barb
Max. Head Pressure
23 psi
Discharge Tube Outlet ID
3/4 in
Max. Oil Flow
8 gpm
Discharge Tube Outlet OD
1 in
Max. Outlet Pressure
23 psi
Explosion Proof
No
Max. Viscosity
10 cps
For Container Size
55 gal, 275 gal, 330 gal
Min. Fluid Temp.
17 Degrees F
For Container Type
Drum, Tote
Noise Level
70 db
For Media Type
Acetic Acid, Ammonium Hydroxide, Antifreeze, Bleach, Citric Acid, DEF, Ethanol, Ethylene Glycol, Formaldehyde, Glycerin, Isopropanol, Potassium Hydroxide (50%), Sodium Bicarbonate, Sodium Bisulfite, Water
Nominal Voltage
110V AC
Frequency (Hz)
60
Not Recommended Chemicals
Acetic Acid (Glacial), Acetic Acid 80%, Acetone, Ammonia (Liquids), Anhydrous Ammonia, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Calcium Chloride, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Cyclohexane, Diesel Fuel, E85, Ethyl Acetate, Fertilizers, Formic Acid, Fungicides, Gasoline, Heptane, Herbicides, Hexane, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Hydrazine, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Kerosene, Lacquer Thinners, Lithium Grease, Methyl (Methanol), Methyl Chloride, Methyl Ethyl Ketone (MEK), Motor Oil, Naphtha, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Paint, Paint Thinner, Pesticides, Phosphoric Acid (40% Solution), Sodium Bisulfate, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Stoddard Solvent (Mineral Spirits), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Sulfuric Acid (to 10%), Toluene, Trichlorethylene (50%), Turpentine, Windshield Washer Fluid, Xylene
Height Above Container
20 in
Nozzle Operation
Automatic
Hose Cover Material
Thermal Plastic
Number of Phases
1
Hose Inside Dia.
3/4 in
Pump Connection OD
1 in
Hose Outside Dia.
1 in
Pump Connection Type
Hose Barb
Hose Tube Material
EPDM
Pump Package Type
Metered Dispensing with Automatic Shut-Off
Housing Material - Pumps
Polypropylene
Rated Voltage
115V AC
Includes
Coupler, Drip Cup, Hose, Meter, Nozzle, Nozzle Hanger, Reel, Steel Tote Mounting Plate
Runs Dry
Yes
Includes Bung Adapter
No
Spout Connection Type
Integral to Nozzle
Includes Discharge Hose
Yes
Spout Discharge Size
3/4 in
Includes Nozzle
Yes
Suction Tube ID
3/4 in
Includes Spout
Yes
Suction Tube Material
EPDM
Includes Suction Tube
Yes
Suction Tube OD
1 in
Max. Flow Rate
8 gpm
Product Description
Diesel exhaust fluid (DEF) stationary electric drum pumps are used specifically with DEF to maintain purity when filling the reservoir of a diesel engine's Selective Catalytic Reduction (SCR) system. These pumps are certified to ISO standards that regulate the handling, transportation, and storage of DEF. They are used for dispensing and transferring moderate to large volumes of DEF when servicing late model trucks and SUVs as well as SCR-based stationary industrial systems that operate on diesel fuel.
