BIG ASS FANS

Big Ass Fans 72", Standard-Duty Industrial Fan, Non-Oscillating, Mobile, Floor, 110-125 VAC

Hover over image to magnify
Portable Floor Fans,6.5 Ft.
PI_Asset_1495718
Portable Floor Fans,6.5 Ft.
PI_Asset_1495718

#935452 | Pkg Qty: 1

$9,277.55 pkg | $9,277.55 ea
Pricing is subject to change without notice

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Amps
4.7
Number of Blades
6
Blade Diameter
72 in.
Number of Conductors
0
Blade Material
Aluminum
Package Quantity
1
Brand
BIG ASS FANS
Phase
1
Hz
50/60 Hz
RPM
291
Item
Standard-Duty Industrial Fan
Shipping Weight
557 lb.
Mfr. Part Number
F-BJ1-0601
Sound Level
43 dBA
Motor Enclosure
Open Dripproof
Voltage
110-125 VAC
NEMA Plug Configuration
5-15P
Wheel Material
Rubber
General
Air Velocity @ 10 Ft.
640 fpm
Fan Overall Type
Commercial/Industrial
Air Velocity @ 40 Ft.
430 fpm
Fan Power Source
Plug-In
Air Velocity @ 60 Ft.
340 fpm
Max. Ambient Temp.
122 Degrees F
Air Velocity @ 80 Ft.
290 fpm
Oscillation
Non-Oscillating
Assembly Required
No
Speed Controllable - Fans
Yes
Battery Operated - Fans
No
Standards
UL, ETL
Environmental Applications
Industrial
Wheel Dia.
8 in
Fan Accessory Finish
Powder Coated
Wheeled Base
Mobile
Fan Housing Material
Steel
Wire Guard Finish
Powder Coated
Fan Mounting Location
Floor

Product Description

Standard-duty industrial mobile and stationary floor fans cool heavy manufacturing areas and other dusty or dirty environments. Compared to light-duty industrial fans, these standard-duty fans are made of heavier-gauge materials, have a higher-horsepower motor, and feature more-robust motor bearings for a longer life.

Industrial mobile and stationary floor fans sit close to the ground to resist tipping over, even when bumped, while providing a powerful stream of air at floor level. These air circulators are often used for spot cooling workstations or production lines and for general cooling in manufacturing plants, warehouses, and shipping operations. Made of heavy-gauge materials suitable for daily use, these axial fans have a powerful motor that drives the fan blades to move large volumes of air and feature high-performance bearings for a long life. A guard encloses the fan blades to help protect them from damage and prevent injuries from accidental contact. Mobile floor fans have wheels, so they can be rolled from one location to another as cooling needs change. Stationary floor fans are used in applications where fans don't need to be frequently relocated, but they are generally light enough to carry between locations.

Item Barcode
9354520
Portable Floor Fans,6.5 Ft.
 NameItemDescription
Grainger DropshipGrainger Dropship699W08
UNSPSC CODESUNSPSC CODES40101604
VMRS (ATA) CODESVMRS (ATA) CODES053-006-009Portable Floor Fans,6.
