DSR Proseries Automatic, Wheeled Battery Charger; Boosting, Charging, Maintaining; For Battery Voltage: 6 V DC, 12 V DC

Hover over image to magnify
Battery Charger,Wheeled,6/12V
PI_Asset_1758582
PI_Asset_1758583
PI_Asset_1770468
PI_Asset_1772559
PI_Asset_1773813
Battery Charger,Wheeled,6/12V
PI_Asset_1758582
PI_Asset_1758583
PI_Asset_1770468
PI_Asset_1772559
PI_Asset_1773813

#927825-8 | Pkg Qty: 1

$320.19 pkg | $320.19 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
AC Cord Length
6 ft.
Indoor/Outdoor
Indoor/Outdoor
Automatic/Manual
Automatic
Input Voltage
120 VAC
Boost Amps @ Voltage
50A @ 12V
Item
Battery Charger
Brand
DSR PROSERIES
Maintaining Amps @ Voltage
0.14A @ 13.2V
CEC Compliant
CEC Compliant
Material
Plastic
Cable Gauge
6 AWG
Mfr. Part Number
DSR131
Cable Length
2 ft.
Overall Depth
11-7/8 in.
Charge Type
Float
Overall Height
24 in.
Charger Function
Boosting, Charging, Maintaining
Overall Width
16 in.
Charger Style
Wheeled
Package Quantity
1
Charging Amps @ Voltage
125A @ 6V, 250A @ 12V
Portable
Yes
Cranking Amps
100A
Power Cord Length
6 ft.
For Battery Voltage
6 V DC, 12 V DC
Shipping Weight
36 lb.
For Use with Battery Type
AGM, Deep Cycle, Gel
Test Feature
No
Housing Material
Plastic
Timer
No
General
Boost Current @ Voltage
50 A @ 12V, 50 A @ 6V
Includes Test Feature
No
Cable Wire Gauge
6 AWG
Indoor / Outdoor
Indoor / Outdoor
Cold Cranking Current @ Voltage
100 A @ 12V
Input Voltage
120 VAC
Green Certification or Other Recognition
California Energy Commission (CEC) Certified
Power Cord Length
6 ft.
Housing Material
Plastic
Standards
cUL, UL
Includes
(4) Cable Clamp Cleats

Product Description

Battery Charger, Charger Style Wheeled, For Battery Voltage 6, 12, For Use With Battery Type AGM, Deep Cycle, Gel, Charger Function Boosting, Charging, Maintaining, Automatic, Charge Type Auto On/Off, Boost Amps @ Voltage 50A @ 12V, Cold Cranking Amps @ Voltage 100A @ 12V, Charging Amps @ Voltage 250A @ 12V, 125A @ 6V, Maintaining Amps @ Voltage 0.14A @ 13.2V, AC Cord Length 6 ft, Input Voltage 120V AC, Input Amps 11, Overall Width 16 in, Overall Height 24 in, Overall Depth 11 7/8 in
