DAKE CORPORATION

Dake Corporation 1/2 Motor HP Bench Drill Press, Belt Drive Type, 14-1/8" Swing, 120 Voltage

Hover over image to magnify
Bench Drill Press,Belt,14-1/8",
PI_Asset_977038
PI_Asset_977039
PI_Asset_977040
Bench Drill Press,Belt,14-1/8",
PI_Asset_977038
PI_Asset_977039
PI_Asset_977040

#927441-4 | Pkg Qty: 1

$2,012.56 pkg | $2,012.56 ea
Pricing is subject to change without notice

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Application
Drilling
Mfr. Part Number
977102-1
Base Length
17-3/4 in.
Package Quantity
1
Base Width
12-1/4 in.
Phase
Single
Brand
DAKE CORPORATION
Primary Material Application
Metal, Wood
Chuck Size
1/2 in.
Shipping Weight
175 lb.
Chuck Type
Keyed
Speed Control
Variable
Current Rating
20 A
Swing
14-1/8 in.
Drive Type
Belt
Table Shape
Square
Horsepower
1/2 HP
Voltage
120V AC
Item
Bench Drill Press
General
Chuck Style
Keyed
Minimum Spindle Speed
545 RPM
Column Diameter
3 1/8 in
Nominal Voltage
115V AC
Coolant System
No
Power Down Feed Included
No
Current
20 A
Quill Diameter
2 in
Downfeed Type
Manual
Radial Arm
No
Drill Press Application
Drilling
Speed Adjustment
Knob
Drill Press Type
Benchtop
Speed Range
545 to 4,000 RPM
Drilling Capacity in Steel
5/8 in
Spindle Speed Range
545 RPM - 4,000 RPM
Drilling Capacity in Wood
5/8 in
Spindle Travel
3 1/8 in
Guard Included
Yes
Spindle-to-Column Distance
7 1/16 in
Includes
Chuck Guard, Drift, Keyed Chuck, HDPE Chip
Table Length
11 3/4 in
Maximum Overall Height
42 1/2 in
Table Slot
Yes
Maximum Spindle Speed
4,000 RPM
Table Slot Width
5/8 in
Maximum Spindle-to-Base Height
26 1/2 in
Table Width
11 3/4 in
Maximum Spindle-to-Table Height
16 1/2 in

Product Description

Bench top variable speed drill press that is ideal for cell applications requiring fast tooling changes. Featuring a locking handle hub for repeatable depth, CE safety electrical package, a large diameter sturdy spindle, and a massive cast head. The speed can be easily adjusted while drilling by turning the large selector knob on the top of the drill.

Item Barcode
9274414
