HUBBELL WIRING DEVICE-KELLEMS
Hubbell Wiring Device-Kellems 30A Industrial Grade Non-Shrouded Watertight Locking Plug, Black; NEMA Configuration: L21-30P
#926995Pkg Qty: 1
$179.88 pkg
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Amperage
30 A
Antimicrobial
No
Brand
HUBBELL WIRING DEVICE-KELLEMS
Color Family
Black
Cord Size
0.325 in. to 0.875 in.
Corrosion Resistant
No
Grade
Industrial
Housing Material
Thermoplastic Elastomer
IP Rating
IP69K
Item
Watertight Locking Plug
Mfr. Part Number
HBL28W81BK
NEMA Configuration - Plugs & Connectors
L21-30
NEMA Plug Configuration
L21-30P
Number of Poles
4
Number of Wires
5
Package Quantity
1
Phase
Three
Shipping Weight
.8 lb.
Voltage
120/208V AC
Wiring Style
Standard
Amperage
30 A
Mfr. Part Number
HBL28W81BK
Antimicrobial
No
NEMA Configuration - Plugs & Connectors
L21-30
Brand
HUBBELL WIRING DEVICE-KELLEMS
NEMA Plug Configuration
L21-30P
Color Family
Black
Number of Poles
4
Cord Size
0.325 in. to 0.875 in.
Number of Wires
5
Corrosion Resistant
No
Package Quantity
1
Grade
Industrial
Phase
Three
Housing Material
Thermoplastic Elastomer
Shipping Weight
.8 lb.
IP Rating
IP69K
Voltage
120/208V AC
Item
Watertight Locking Plug
Wiring Style
Standard
General
Amps - Plugs and Receptacles
30
Blade Material
Nickel-Plated Brass
Body Length
2.77 in.
Connection Orientation
Straight
Current Rating
30 A
Description
Twist Lock
HP
3.0 HP
HP
3.0
Horsepower
3 hp
Housing Color
Black
Material
Thermoplastic Elastomer, Valox
Maximum Operating Temperature
60 °C
Minimum Operating Temperature
-40 °C
NEMA Plug Configuration - Plugs and Receptacles
L21-30P
NEMA Rating
4, 4X, 6, 6P
Number of Blades
5
Outside Diameter
2.77 in.
Overall Length
2.77 in.
Polarized
Yes
Shrouded
No
Special Features
Moisture, Dust and Weather Resistant
Standards
ANSI, NEMA WD-1 and WD-6
Voltage - Plugs and Receptacles
120/208V AC
Wire Connection Type
Screw Terminals
Amps - Plugs and Receptacles
30
Minimum Operating Temperature
-40 °C
Blade Material
Nickel-Plated Brass
NEMA Plug Configuration - Plugs and Receptacles
L21-30P
Body Length
2.77 in.
NEMA Rating
4, 4X, 6, 6P
Connection Orientation
Straight
Number of Blades
5
Current Rating
30 A
Outside Diameter
2.77 in.
Description
Twist Lock
Overall Length
2.77 in.
HP
3.0 HP
Polarized
Yes
HP
3.0
Shrouded
No
Horsepower
3 hp
Special Features
Moisture, Dust and Weather Resistant
Housing Color
Black
Standards
ANSI, NEMA WD-1 and WD-6
Material
Thermoplastic Elastomer, Valox
Voltage - Plugs and Receptacles
120/208V AC
Maximum Operating Temperature
60 °C
Wire Connection Type
Screw Terminals
Product Description
Features keyed interior for easy installation and high conductivity brass termination. Also designed with Gotcha® ring and collapsible bushing strain relief. The strain relief nut seals on the body, eliminating areas of debris collection, and provides impact resistance. Unique cone seal prevents dirt and debris from collecting at cable entrance. Triple bypass seal keeps water away from electrical connections. Smooth body design minimizes collection points and simplifies wash down process. Also features cone seal that adjusts to various cable ranges. All stainless steel hardware and corrosion-resistant connection points.
Item Barcode
Wt Plug,L21-30P,30A,120/208VAC,
