UNITED BRASS WORKS
FNPT Gate Valve, Inlet to Outlet Length: 1-21/32", Pipe Size: 3/4", Max. Fluid Temp.: 406°F
Hover over image to magnify
#926963-6 | Pkg Qty: 1
$1,612.18 pkg | $1,612.18 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Body Material
Bronze
Mfr. Part Number
294001
Brand
UNITED BRASS WORKS
Package Quantity
1
Connection Type
FNPT
Pipe Size
3/4 in.
Handle Material
Ductile Cast Iron
Shipping Weight
3.45 lb.
Handle Type
Hand Wheel
Stem Material
Brass
Item
Gate Valve
Stem Type
Rising
General
Body Material - Valves
Bronze
Top of Handle to Inlet Center
7 25/32 in
Inlet to Outlet Length
1 21/32 in
Valve Max. Fluid Temp.
406 Degrees F
Max. Water Pressure - CWP
385 psi
Valve Stem Type
Rising
Pipe Size - Valves
3/4 in
Wedge Material
Stainless Steel
Standards
MSS-SP-80-97, CRN OCO7135.2C
Product Description
Blowdown and Blowoff Gate Valves
- Blowdown models are bronze, Blowoff valves are carbon steel
- Max. pressure: 385 psig Blowdown; 650 psi WSP at 500°F, 750 psi WSP at 100°F Blowoff Max. temp.: 406°F Blowdown, 500°F Blowoff
- Feature rugged stainless steel seat and disc hardened to 60 Rockwell C for superior service in harsh environments. Blowdown valves have a calibrated easy-to-read gauge and pointer for accurate metering. Blowoff valves are epoxy-coated to help resist corrosion, and have a sliding disc design that provides a cleaning action to help keep the seating area clear of scale and debris.
- Meet ANSI B16.34 standard. Blowdown models meet MSS SP80-97 standard.
Item Barcode
Gate Valve,3/4 In.,Fnpt,Bronze
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 45A322 | Gate Valve,3/ 4 In.,FNPT, |
 | UNSPSC CODES | 40141613 | |
 | VMRS (ATA) CODES | 053-008-004 | Gate Valve,3/ 4 In.,FNPT, |
