VIBRA-TITE

Vibra-Tite High-Strength Threadlocker: 131, Red, High-Temp Resistant, 1.69 fl oz, Bottle, 1 EA

Hover over image to magnify
Threadlocker,Red,50mL,Gap 0.
Threadlocker,Red,50mL,Gap 0.

#926311-8 | Pkg Qty: 1

$24.21 pkg | $24.21 ea

Technical Specifications

Key Specifications
Appearance
Red
Pack Quantity
1
Application
General Purpose Bolts and Nuts
Performance Temperature Range
-60° to 300°F
Begins to Harden
4 min.
Physical Form
Liquid
Brand
VIBRA-TITE
Removable With
Heat and Hand Tools
Chemical Type
Anaerobic
Series
131
Color Family
Red
Shipping Weight
.16 lb.
Container Type
Threadlocker/ Sealant Bottle
Standards
MIL-S-46163A, ASTM D-5363, NSF Non-Food
For Fastener Diameter
Up to 1 in.
Temperature Range
-60 Degrees to 300 deg. F
Full Cure
24 hr.
Threadlocker Classification
Threadlocker
Gap Fill
0.007 in.
Threadlocker Disassembly
Permanent
Item
Threadlocker
Threadlocker Strength
High Strength
Net Weight
50 mL
Viscosity
1800 to 5000 cP
General
Breakaway Torque
200 in-lb
Pack Size
1 EA
Breakaway Torque Range
101 in-lb to 200 in-lb
Prevailing Torque
250 in-lb
Compatible Materials
Bronze, Copper, Iron, Manganese, Nickel, Steel
Product Form
Liquid
Compatible Primer ( Part Number)
49CH64
Removal Method
Hand Tool and Heat
Compatible Primer Series
Vibra-Tite 611
Storage Requirements
14 Degrees to 86 Degrees F
Container Size Range
Over 1.1 oz
Threadlocker Properties
High-Temperature Resistant
Container Size and Type
1.69 fl oz Bottle
Threadlocking Properties
High-Temperature Resistant
Container and Size
Bottle Over 1.1 oz
Threadlocking Strength
High
Cure Type
Anaerobic
Torque and Strength
200 in-lb High
For Material Type
Brass, Bronze, Copper, Iron, Manganese, Monel, Nickel, Steel
VOC Content Range
11 g/L to 50 g/L
For Maximum Thread Diameter
1 in
Working Time
4 min
Minimum Viscosity
1,800 cps
Working Time Range
5 min or Less

Product Description

Threadlocker, Threadlocker, Threadlocker Strength High, Threadlocker Color Red, Threadlocker Disassembly Permanent, Physical Form Liquid, Threadlocker Container Bottle, 50 mL, Chemical Type Anaerobic, For Fastener Dia. Up to 1 in, Begins to Harden 4 min, Series 131, Gap Fill 0.007 in, Full Cure 24 hr, Temp. Range -60 Degrees to 300 Degrees F, Flash Point 268 Degrees F, Specific Gravity 1.1, Viscosity 1800 to 5000 cP, Removable With Heat and Hand Tools

Compliance & Restrictions

SDS Available
SDS Available View
Item Barcode
9263118
Threadlocker,Red,50mL,Gap 0.
  Name Item Description
Grainger Dropship Grainger Dropship 49CF46 Threadlocker, Red,50mL,Gap
UNSPSC CODES UNSPSC CODES 31201701
VMRS (ATA) CODES VMRS (ATA) CODES 053-999-075 Threadlocker, Red,50mL,Gap
