HUBBELL WIRING DEVICE-KELLEMS
Hubbell Wiring Device-Kellems 50A Industrial Grade Straight Blade Plug, Black/White; NEMA Configuration: 14-50P
Hover over image to magnify
#920459-6 | Pkg Qty: 1
$151.01 pkg | $151.01 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Amps
50 A
Material
Nylon
Antimicrobial
No
Maximum Operating Temperature
75 °C
Body Length
4.13 in.
Maximum Wire Size
4 AWG
Boot Code
C
Mfr. Part Number
HBL9451C
Brand
HUBBELL WIRING DEVICE-KELLEMS
Minimum Operating Temperature
-40 °C
Color Family
Black
Minimum Wire Size
12 AWG
Connection Orientation
Straight
NEMA Configuration - Plugs & Connectors
14-50
Cord Size
0.625 in. to 1.310 in.
Number of Blades
4
Corrosion Resistant
Yes
Number of Poles
3
Current Rating
50 A
Number of Wires
4
Description
Insulgrip, Grounding
Package Quantity
1
For Maximum Cable Diameter
1.31 in.
Phase
Single
For Minimum Cable Diameter
0.625 in.
Polarized
Yes
Grade
Industrial
Shipping Weight
.75 lb.
Grounding
Grounded
Standards
CSA Certified, UL E1706
Horsepower
2 hp, 3 hp
Subcategory
Plugs
Housing Color
Black
UL 94 Flammability Rating
HB
Housing Material
Nylon
Voltage
125/250V AC
IP Rating
IP20
Wire Connection Type
Screw Terminals
Insulation Material
Nylon
Wiring Style
Standard
Item
Straight Blade Plug
General
Amps - Plugs and Receptacles
50 A
NEMA Plug Configuration - Plugs and Receptacles
14-50P
Grade - Plugs and Receptacles
Industrial
Phase - Plugs and Receptacles
3
HP
2.0 Line to Neutral, 3.0 Line to Line
Voltage - Plugs and Receptacles
125/250V AC
Product Description
Hubbell® Plugs Heavy-duty cord clamps handle a wide range of cable sizes and hold conductors securely in place. Nylon bodies withstand severe abuse. 4-position angle plugs allow cord to enter from top, bottom, or either side and stay close to wall. High-Ampere Plugs and Receptacles CSA Certified. Note: See page 611 for NEMA configurations.
Expertly Selected Product Pairings
Item Barcode
Plug,14-50P,50A,125/250V
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 5Z886 | Plug,14-50P, 50A,125/250V |
 | UNSPSC CODES | 39121402 | |
 | VMRS (ATA) CODES | 053-006-009 | Plug,14-50P, 50A,125/250V |
