SPEEDAIRE
Desiccant Filter/Dryer: 5-Stage, ISO Class 2, 1/2 in NPT, 40 cfm, 120 psi Max Op Pressure
Hover over image to magnify
#920125-4 | Pkg Qty: 1
$508.30 pkg | $508.30 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
(F)NPT Inlet
1/2 in.
Item
Desiccant Filter/Dryer
(M)NPT Outlet
1/2 in.
Maximum Operating PSI
175
Air Consumption
scfm
Maximum SCFM @ 100 PSI
40 psi
Bowl
Clear Poly
Mfr. Part Number
2YNL4
Brand
SPEEDAIRE
Microns
40 and 250
CFM
40
Package Quantity
1
Diameter
4 in.
Shipping Weight
13.05 lb.
Element Material
Sintered Bronze/paper pleaded
Type
Quiet Flow
ISO Class
2
Width
4 in.
General
Air Inlet Type
NPT
Filtered Substance
Debris, Dirt, Dust, Oil, Oil Vapor, Water, Water Vapor
Air Outlet Size
1/2 in
ISO Class - Air Treatment
2
Air Outlet Type
NPT
Includes
Mounting Brackets, Safety Guard
Application
Dry Air
Max. Flow - Air Treatment
40 cfm
Bowl Guard Included
Yes
Max. Incoming Pressure - Air Treatment
175 psi
Bracket Kit Included
Yes
Maximum Flow @ 100 psi
40
Connection Size - Air Treatment
1/2 in NPT
Multi-Stage Air Dryers
5-Stage
Desiccant Material
Silica Gel
Number of Air Inlets
1
Dew Point (Deg. F)
-30
Number of Air Outlets
1
Dew Point - Air Treatment
-30°F
Stage 1 Filter Type
0.4 micron Sintered Bronze Filter
Disposable
Yes
Stage 4 Filter Type
0.4 micron Sintered Bronze Filter
Filter Element Material
Sintered Bronze
Total Capacity (Cu.-Ft.)
5000
Filter Included
Yes
Total Capacity - Air Treatment
5,000 cu ft
Product Description
Ideal for drying small volumes of air at the point of use. Protect branch lines exposed to temperatures below freezing. Convenient in-line mounting saves space. Premeasured desiccant packaged in convenient, easy-to-use bags for less waste. ISO Class dryer capacities established at 100°F ambient temp., 100 psig.
