AMERICAN STANDARD

Toilet Bowl: American Std Madera(TM) FloWise(R), 1.1/1.28/1.6 Gallons per Flush, Elongated Bowl

Hover over image to magnify
Toilet Bowl,Floor,Elongated,16-
PI_Asset_928882
PI_Asset_928883
PI_Asset_928884
PI_Asset_928885
PI_Asset_928886
Toilet Bowl,Floor,Elongated,16-
PI_Asset_928882
PI_Asset_928883
PI_Asset_928884
PI_Asset_928885
PI_Asset_928886

#918289-3 | Pkg Qty: 1

$198.87 pkg | $198.87 ea

Drop Ship Item

Shipping to 60045

Required Items

Items below are required. They are not included and need to be ordered separately.
Exposed,Top Spud,Automatic
Pkg Qty: 1
$434.51 pkg
Exposed,Top Spud,Automatic
Pkg Qty: 1
$434.51 pkg
Exposed,Top Spud,Automatic
Pkg Qty: 1
$434.51 pkg

Technical Specifications

Key Specifications
Bowl Depth
27-1/4 in.
Height
16-1/2 in.
Bowl Height
16-1/2 in.
Item
Toilet Bowl
Bowl Shape
Elongated
Material
Vitreous China with EverClean
Bowl Width
14 in.
Mfr. Part Number
3461001.02
Brand
AMERICAN STANDARD
Mounting
Floor
Color Family
White
Package Quantity
1
Connection
1-1/2 in. Inlet Spud
Shipping Weight
65.5 lb.
Depth
28-1/4 in.
Width
14 in.
General
Brand and Series
American Standard Madera(TM) FloWise(R)
Spud Connection Size
1 1/2 in
Features
Siphon Jet, MaP Score of 1,000 Grams, Everclean® Surface Inhibits the Growth of Stain and Odor Causing Bacteria, Mold & Mildew & Condensation Channel, Fully Glazed Trapway
Spud Location
Top
Flushing Method
Flush Valve
Stain Resistant
Yes
For Use With
Top Spud Flushometer
Standards
ASME A112.19.2 2008/ CSA B45.1 08, ADA , ANSI 117.1
Gallons per Flush
1.1, 1.28, 1.6
Toilet Bowl Material
Vitreous China
Green Certification/Other Recognition
WaterSense Certified and California Energy Commission (CEC) Certified
Toilet Bowl Shape
Elongated
Green Environmental
Toilet Uses 1.28 gpf or Less
Toilet Mounting Style
Floor
Includes
Inlet Spud and Bolt Cap
Toilet Product Type
Toilet Bowl
Includes Bowl
Yes
Trapway Dia.
2 1/8 in
Rim Height
16 1/2 in
Water Surface Area
10 in x 12 in
Rough-In
10 in, 12 in

Product Description

These floor-mount tankless toilet bowls connect to a floor waste line and have a top spud to work with an exposed flush valve for unblocked access during maintenance. They fasten to the floor for stability and support more weight than wall-mounted toilets. These bowls have a bottom outlet for the waste line and a spud on the rear rim atop the bowl for connecting to a flush valve (flushometer).
