BESSEY

Bessey Sliding Arm Bar Clamp,20 Max. Jaw Opening (In.),2660 Nominal Clamping Pressure

Hover over image to magnify
Sliding Arm Bar Clamp,20 In,5-
Sliding Arm Bar Clamp,20 In,5-

#916055-6 | Pkg Qty: 1

$120.22 pkg | $120.22 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Bar Material
Steel
Load Capacity
2600 lb.
Brand
BESSEY
Maximum Opening
20 in.
Clamping Force
2,600 lb.
Mfr. Part Number
GSM50
Duty Rating
Heavy Duty
Package Quantity
1
Handle Material
Tempered Drop-Forged Steel
Pad Style
Swivel, Heavy Duty
Handle Style
Sliding T
Shape
F
Item
Bar Clamp
Shipping Weight
8.2 lb.
Jaw Opening
20 in.
Throat Depth
5-1/2 in.
General
Application
Heavy Maintenance, Welding, Assembly And General Purpose Clamping
Max. Jaw Opening (In.)
20 in
Bar Size (In.)
7/16 in
Nominal Clamping Pressure
2660
Bar Thickness (In.)
1 3/16 in
Nominal Rail Size (In.)
1-3/16 x 19/32
Bar Width (In.)
19/32 in
Opening (In.)
20 in
Clamp Face (In.)
1-5/16 x 2-5/8
Screw Size (In.)
0.775
Clamping Surface D (In.)
1 5/16 in
Spindle Dia. (In.)
0.775
Clamping Surface W (In.)
2 5/8 in
Throat Depth (In.)
5 1/2 in
Handle Length (In.)
4 11/16 in

Product Description

The BESSEY® classiX® sliding arm bar clamp offers an abbreviated range of the most popular clamp performance characteristics for industrial applications. Heavy-duty swivel pads are field replaceable. All-steel heavy-duty bar clamp features a heat-treated, spatter-resistant spindle, swivel-tilting pressure pad, and a vibration-dampening design. Arc of the curve enable rail to hug work piece. Fixed arm and pressure plate are tempered steel.
