CLEVELAND

Square End Mill, 3/8" Milling Diameter, Number of Flutes: 4, 1-1/2" Length of Cut, TiN, HG4CTN

Hover over image to magnify
Hss End Mill,3/8 In D,1 1/2 In
Hss End Mill,3/8 In D,1 1/2 In
Square End Mill, 3/8" Milling Diameter, Number of Flutes: 4, 1-1/2" Length of Cut, TiN, HG4CTN Video

#915651-8 | Pkg Qty: 1

$36.96 pkg | $36.96 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Brand
CLEVELAND
Helix Angle
30 deg.
Chip-Breaker
No
Item
Square End Mill
Corner Radius
3-1/4 in.
Length of Cut
1-1/2 in.
Cutting Direction
Right
List Number
HG-4C-TN
Cutting Direction
Right Hand
Material
High Speed Steel
Cutting Type
Center
Mfr. Part Number
C33390
Diameter
3/8 in.
Milling Diameter
3/8 in.
Dimension Type
Fractional Inch
Neck Length
Not Applicable
End
Single
Number of Flutes
4
End Mill Application
Finishing
Overall Length
3-1/4 in.
End Mill Cutting Type
Center Cutting
Pack Quantity
1
End Mill Material
High Speed Steel
Primary Material Application
Cast Iron, Steel
End Style
Square End
Shank Diameter
3/8 in.
Finish
TiN
Shipping Weight
0.09 lb.
Grade
General Purpose
Single End/Double End
Single End
General
Application
Alloy Steel, Tool Steel, Cast Iron, Copper
Measurement System
Fractional Inch
Drilling Tool Configuration
Individual
Milling Dia.
3/8 in
End Mill Style
Square
Miniature End Mill
No
Finish - Machining
TiN
Primary Material Application ISO Code
K, P
Material - Machining
High Speed Steel
Shank Dia.
3/8 in
Material Grade - Machining
General Purpose
Shank Type - Machining
Weldon Flat

Product Description

Four-flute end mills clear chips more quickly than end mills with more flutes and allow for higher feed rates than end mills with fewer flutes. They also typically have larger cores and are less prone to breaking than end mills with fewer flutes. The TiN coating on these end mills protects them from wear and resists impact better than TiAlN and AlTiN coatings.

General purpose high-speed steel square end mills are intended for milling a wide variety of common materials but are not suitable for milling hard materials like titanium or gummy materials like aluminum. Finishing end mills create a finer finish on the workpiece than roughing and roughing/finishing end mills. High-speed steel square end mills offer good wear resistance for basic milling applications. They're more flexible and can absorb more shock and vibration than carbide, cobalt, or powdered-metal end mills. These end mills have a coating that protects them from wear. Sometimes called square-nose end mills, square end mills have a square nose and are rotated against a piece of stock to create a flat-bottomed groove with 90° inside corners in milling tasks. They are used for counterboring, side and face milling, and milling square shoulders.
