Technical Specifications
Key Specifications
Appearance
Red
Pack Quantity
1
Application
For Fasteners Up to 3/4 in Dia Convenient Stick Package
Performance Temperature Range
-65° to 300°F
Begins to Harden
5 min.
Physical Form
Solid
Brand
LOCTITE
Removable With
Heat and Hand Tools
Chemical Type
Anaerobic
Series
268
Color Family
Red
Shipping Weight
0.08 lb.
Container Type
Stick
Size
0.67 oz.
Fills
Gaps Between Threads
Specific Gravity
1.1
Fixture Time
5 min.
Standards
OSHA Hazard Communication
Flash Point
Product is a solid
Temperature Range
-65 Degrees to 300 deg. F
For Fastener Diameter
Up to 3/4 in.
Threadlocker Classification
Threadlocker
Full Cure
24 hr.
Threadlocker Disassembly
Permanent
Gap Fill
0.005 in.
Threadlocker Strength
High Strength
Item
Threadlocker
Type
Medium to High Strength Threadlocker
Mfr. Part Number
826035
Viscosity
Semisolid
Net Weight
0.67 oz.
General
Breakaway Torque
90 in-lb
Pack Size
1 EA
Breakaway Torque Range
51 in-lb to 100 in-lb
Product Form
Solid
Clean Up Method
Solvent, Wire Brush
Recommended Surface Preparation
Dry Surface
Compatible Materials
Bronze, Copper, Iron, Manganese, Nickel, Steel
Removal Method
Heat
Compatible Primer ( Part Number)
4KL11
Storage Requirements
8 Degrees to 21 Degrees C
Compatible Primer Series
Loctite 7649
Threadlocker Properties
No-Drip
Container Size Range
0.4 oz to 1 oz
Threadlocking Properties
No-Drip
Container Size and Type
0.67 oz Stick
Threadlocking Strength
High
Container and Size
Stick 0.4 oz to 1 oz
Torque and Strength
90 in-lb High
Cure Type
Anaerobic
VOC Content Range
10 g/L and Under
For Material Type
Brass, Bronze, Copper, Iron, Manganese, Monel, Nickel, Steel
VOC Content Weight Percentage
0.0001
For Maximum Thread Diameter
3/4 in
Working Time
5 min
Mixing Required
No
Working Time Range
5 min or Less
Product Description
Specialty Threadlockers
- Fill gaps between threads and securely mate surfaces to form solid, unitized assemblies. Prevent fasteners from loosening due to vibration and protect against rust and corrosion
- No-Mess Stick
- Semisolid Loctite® stick formula won't spill or leak.
Item Barcode
Threadlocker, Red 19GM
| Name | Item | Description | |
|---|---|---|---|
|
Grainger Dropship | 3UU57 | THREADLOCKER RED 19GM |
|
UNSPSC CODES | 31201701 | |
|
VMRS (ATA) CODES | 053-006-009 |
