WELLER
Weller Soldering Tip: ET Series, Screwdriver, 2.4 mm W, 34.5 mm Lg
Hover over image to magnify
#911206-4 | Pkg Qty: 1
$7.63 pkg | $7.63 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Application
Soldering
Operating Temperature Range
850 deg.
Brand
WELLER
Package Quantity
1
Compatible Handpiece
EC1201A, EC1204A, PES50, PES51, WCC101, WEP 70
Product Size
0.63 in.
Compatible Station
WD1, WD2, WE1010, WE1010EDU, WE1010NA, WES50, WES51, WES51PU, WESD51PU
Series
Et
Contains Lead
Yes
Shipping Weight
.02 lb.
Contents
Flux
Tip Length
34.5 mm
Fits With
1UNE4, 5JH82, 2UV18
Tip Size
0.093 in.
Item
Soldering Tip
Tip Thickness
0.51 mm
Material
Plated Copper
Tip Type
Screwdriver
Melting Range
Max 850 deg.
Tip Width
2.4 mm
Mfr. Part Number
ETB
Type
Screwdriver
Operating Temperature
850 deg.
General
Compatible Handpiece Manufacturer
Weller
Tip Outside Diameter
2.4 mm
Compatible Handpiece Manufacturer Model Number
EC1201A, EC1204A, PES50, PES51, WCC101, WEP 70
Tip Size (In.)
0.093
Compatible Station
WD1, WD2, WE1010, WE1010EDU, WE1010NA, WES50, WES51, WES51PU, WESD51PU
Tip Size (mm)
2.4
ESD Safe
No
Tip Thickness
0.51 mm
For Use With
PES51, WES51, WESD51
Tip Width
2.4 mm
Tip Length
34.5 mm
Product Description
Digital and Analog Soldering/Desoldering Stations
- All units are ESD-safe to protect sensitive components. 120V, 60 Hz, except Compact Part Numbers: 6KCK6 and 6KCK7 are 100-240V.
Expertly Selected Product Pairings
Item Barcode
Solder Tip, Screwdriver, 0.093
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 1UNG1 | SOLDER TIP, SCRWDRVR.093 |
 | UNSPSC CODES | 23271809 | |
 | VMRS (ATA) CODES | 053-006-017 | SOLDER TIP |
