Best Seller

Imperial® Seal-A-Crimp® Niac Sealed Heat Shrink Male Quick Disconnect, Yellow, 12-10 Awg

Zoom Icon
Secondary Item Image
Secondary Product Video

#80205 | Pkg Qty: 50

Item Number 80205
Scanner Description Sealed Yel Ml Qk Ds
Inventory Status In Stock
Weight 0.24 lb
Brand IMPERIAL
Trade Name SEAL-A-CRIMP
Catalog E2

Technical Specifications

Brand
IMPERIAL
Item
Heat Shrink Terminal
Color Family
Yellow
Pack Quantity
50
Connection Material
Copper
Tab Thickness
0.03 in.
Connection Type
Crimp
Tab Width
1/4 in.
Connector Style
Sealed
Temperature Range (Deg C)
-55 to +125 deg. C
Features
Male Quick Disconnect
Temperature Range (Deg F)
-67 to +257 deg. F
Heat Shrink Terminal Connector
Male Quick Disconnect
Trade Name
SEAL-A-CRIMP
Insulation Material
NiAc
Wire Gauge Range
12-10 AWG
Insulation Type
Heat Shrink

Product Description

Seal-A-Crimp Premium Insulated Quick Disconnect Terminal

  • A Totally Environmental Sealed Terminal Connection. Simply Crimp And Heat. A Special Polyolefin Heat Shrink Tubing Is Utilized With An Adhesive Inner Liner That Melts And Adheres As The Tubing Shrinks, Providing A Complete Environmental Seal.
  • Tubing Will Not Shrink In Length, Providing Additional Insulation And Strain Relief.
  • Brazed Seam Connector Prevents Opening Of Connector Barrel When Crimped.
  • Operating Temperature Range: -55 C. To 110 C.
  • Style: Male
  • Color: Yellow
  • Wire Range: 12-10
  • Tab Size: Width: .250, Thickness: .030

Compliance & Restrictions

Lot Tracked Item Lot tracked item

Documents

Item Barcode
0802050
349-1 Seal-A-Crimp® Ring, Qiuck Disconnect & Butt Connector Terminals Assortment, 325 Pieces
349-7 Seal-A-Crimp Terminal Asst
350-1 Seal-A-Crimp® Ring, Spade, Snap, Quick Disconnect & Butt Connector Terminals Assortment, 345 Pieces
350-7 Seal-A-Crimp Terminals
352-1 Nycrimp® Insulated Ring, Spade, Snap, Quick Disconnect, Butt, Hook & Multi-Stud Terminals Assortment, 426 Pieces
  Name Item Description
Phillips Phillips 1-1966 SEAL-A-CRIMPMALE QK DISC
Your number AUVECO 13680 SEAL-A-CRIMP MALE QK DISC
UNSPSC CODES UNSPSC CODES 39121432
VMRS (ATA) CODES VMRS (ATA) CODES 053-007-002 SEAL-A-CRIMP MALE QK DISC
