Imperial Seal-A-Crimp Niac Sealed Heat Shrink Male Quick Disconnect, Red, 20-18 Awg

Hover over image to magnify
Sealed Red Ml Qk Ds
Sealed Red Ml Qk Ds
Imperial Seal-A-Crimp Niac Sealed Heat Shrink Male Quick Disconnect, Red, 20-18 Awg Video

#80201 | Pkg Qty: 50

In Stock

Shipping to 60045
Catalog: E2

Technical Specifications

Brand
IMPERIAL
Package Quantity
50
Color Family
Red
Shipping Weight
0.16 lb.
Connection Material
Copper
Tab Thickness
0.03 in.
Connection Type
Crimp
Tab Width
1/4 in.
Connector Style
Sealed
Temperature Range (Deg. C)
-55 to +125 deg. C
Heat Shrink Terminal Connector
Male Quick Disconnect
Temperature Range (Deg. F)
-67 to +257 deg. F
Insulation Material
NiAc
Trade Name
SEAL-A-CRIMP
Insulation Type
Heat Shrink
Wire Gauge Range
20-18 AWG
Item
Heat Shrink Terminal

Product Description

Seal-A-Crimp Premium Insulated Quick Disconnect Terminal
  • A Totally Environmental Sealed Terminal Connection.
  • Simply Crimp And Heat. A Special Polyolefin Heat Shrink Tubing Is Utilized With An Adhesive Inner Liner That Melts And Adheres As The Tubing Shrinks, Providing A Complete Environmental Seal.
  • Tubing Will Not Shrink In Length, Providing Additional Insulation And Strain Relief.
  • Brazed Seam Connector Prevents Opening Of Connector Barrel When Crimped.
  • Operating Temperature Range: -55 C. To 110 C.
  • Style: Male
  • Color: Red
  • Wire Range: 20-18
  • Tab Size: Width: .250, Thickness: .030
