#937380-7 | Pkg Qty: 1
$24.01 pkg
| $24.01 ea
Technical Specifications
Key Specifications
Brand
OSG
Shipping Weight
0.11 lb.
Cutting Direction
Right
Size
1/2 in.
Cutting Direction
Right Hand
Spiral Direction
Neutral
Finish
Steam Oxide
Square Size
0.275 in.
Flutes
3
Subgroup | Tap
Spiral Point
Item
Spiral Point Tap
Tap Chamfer
Plug
List Number
105
Tap Dimension Type
Inch
Material
High Speed Steel
Tap Finish
Black Oxide
Mfr. Part Number
1232401
Tap Material
High Speed Steel
Number of Flutes
3
Tap Size
1/2 in.
Number of Pieces
1
Tap Style
Spiral Point
Overall Length
3-11/32 in.
Tap Thread Size
1/2 in.-13
Pack Quantity
1
Tap Thread Type
UNC
Pitch
13
Thread Direction
Right Hand
Pitch Diameter Limits
H3
Thread Length
15/16 in.
Primary Material Application
Aluminum, Cast Iron, Steel
Thread Type
UNC
Series
105
Tolerance
3B
Shank Diameter
11/64 in.
Type
Plug
Shank Length
1-31/32 in. in.
General
55% Thread Drill Size
11.30 mm
Shank Dia.
11/64 in
65% Thread Drill Size
11.00 mm
Shank Type - Machining
Straight
75% Thread Drill Size
0.4219 in
Standards
ANSI
Application
General Machining Taps
Tap Grouping
Individual
Class of Fit
JIS 2
Thread Limit
H3
Coolant Fed
Non-Coolant Through
Thread Limit / Class of Fit
H3 / JIS 2
Extended Neck
Yes
Thread Standard
UNC
Measurement System
Fractional Inch
Threads per Inch
13
Primary Material Application ISO Code
K, N, P
Product Description
The black-oxide finish on these taps retains lubricants to improve the taps' wear resistance and chip flow. Black-oxide taps should only be used on ferrous metals.
