TRUMETER

Trumeter Electronic Counter, Number of Digits: 8, LCD Display, Max. Counts per Second: 40

Hover over image to magnify
Electronic Counter,8 Digits,3
Electronic Counter,8 Digits,3

#931678-5 | Pkg Qty: 1

$23.66 pkg | $23.66 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Accuracy
1
Length
1-3/4 in.
Brand
TRUMETER
Maximum Counts per Second
40
Character Height
0.28 in.
Mfr. Part Number
3400-0000
Connector Type
Tabs
Mounting
2-Hole Rectangular
Depth
1.09 in.
NEMA Rating
12, 4, 4X
Diameter
2.87 in.
Number of Digits
8
Display
LCD
Output
Open-Drain MOSFET
Fits
1.45 in. x 0.95 in. Panel Cutout
Pack Quantity
1
Fits Panel Cut Out
1.45 in. x 0.95 in.
Power Required
Self Powered (15+ yr. Battery)
Height
1.1 in.
Relay
No
IP Rating
66
Reset Type
None
Input Signal
10 to 300V DC, 20 to 300V AC (50/60 Hz)
Series
34
Input Voltage
Internal Lithium Battery
Shipping Weight
.06 lb.
Interface
None
Type
Electronic
Item
Electronic Counter
Width
1.43 in.
General
Counts per Second
40 Pulses per Second Max
Scaler
No
Min. On/Off Pulse
1 msec
Special Features
Totally Sealed From Moisture And Dirt, Programmable Output Thresholds, Front Panel Programmable
Output Rating
0.1A @ 30V DC
Standards
CE, EMC Compliance: EN61326:1997 With A1:1998 and A2:2001, RoHS Compliant, SAE, UL/cUL File ELIY2.E36690
Preset
3

Product Description

Redington Hour Meters and Counters 3410 and 3400 Series

  • 8-digit display has 7mm characters Conform to NEMA 4, 4X, and 12 specifications. Solid-state circuitry has no moving parts to break or wear out. Compact counters require minimal behind-the-panel space. Lens is polarized for easy viewing even in sunlight. Epoxy-encapsulated for max. protection against vibration, shock, and water. UL and C-UL Recognized, CE Certified, RoHS Compliant.
