HUBBELL WIRING DEVICE-KELLEMS

Hubbell Wiring Device-Kellems Black Flanged Locking Inlet, 50 Amps, 125/250 VAC Voltage, NEMA Configuration: Non-NEMA

Hover over image to magnify
Flanged Locking Inlet,
PI_Asset_1983492
Flanged Locking Inlet,
PI_Asset_1983492

#927472-5 | Pkg Qty: 1

$184.01 pkg | $184.01 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Amperage
50 A
Minimum Operating Temperature
-40 °C
Amps
50 A
Minimum Wire Size
10 AWG
Blade Material
Brass
Mount Type
Flush
Brand
HUBBELL WIRING DEVICE-KELLEMS
Mounting Type
Flush Mount
Color Family
Silver
NEMA Enclosure Rating
12, 4, 4X
Current Rating
50 A
NEMA Plug Configuration
Non-NEMA
Face Diameter
2.172 in.
NEMA Rating
12, 4, 4X
Flange Diameter
3-1/2 in.
Number of Blades
4
Flange Material
Steel
Number of Poles
3
Flange Type
Flanged
Number of Wires
4
For Environment
Dry
Overall Depth
2-5/8 in.
For Location
Indoor
Package Quantity
1
Grade
General Use
Phase
Single
Grounding
Grounded
Shipping Weight
.9 lb.
Housing Color
Silver
Shrouded
No
Housing Material
Steel
Special Features
Corrosion Resistant
Housing Material Finish
Zinc Plated
Standards
CSA C22.2 No. 42, UL 498
IP Rating
IP20
Subcategory
Inlets
Item
Flanged Locking Inlet
Type
50A
Material
Zinc-Plated Steel
UL 94 Flammability Rating
V-0
Material of Construction
Steel/Rynite
Voltage
125/250V AC
Maximum Operating Temperature
75 °C
Voltage Rating
125/250V AC
Maximum Wire Size
6 AWG
Wire Connection Type
Screw Terminals
Mfr. Part Number
CS6375
Wiring Style
Standard
General
Special Features
Corrosion Resistant

Product Description

50A Locking Devices

  • Hubbell® Twist-Lock®
  • Box terminal with Allen-head threaded lug permits high clamping pressure on conductors without damaging the threads. Receptacles have chrome-plated brass nosepieces that cannot be distorted to mate with the wrong device. Connectors and plugs have a super-tough, ribbed-nylon housing for superior impact/crush resistance and secure gripping. Stainless steel shroud on plugs protects plug blades from damage.
