General Purpose Threaded Stem Caster: 4 in Wheel Dia., 150 lb, Swivel Caster, Std

Hover over image to magnify
Stem Caster,Swivel,150 Lb.,4in.
Stem Caster,Swivel,150 Lb.,4in.

#927369 | Pkg Qty: 1

$15.21 pkg | $15.21 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Brand
APPROVED SUPPLIER
Load Rating
150 lb.
Caster Brake Included
No
Mfr. Part Number
32J806
Caster Core Material
Polyolefin
Mounting Type
5B
Caster Group
Swivel Caster
Non-Marking
Yes
Caster Load Rating Range
Light Duty
Number of Wheels
1
Caster Raceway
Double Ball
Overall Height
4-13/16 in.
Caster Stem Type
Threaded
Package Quantity
1
Caster Sub-Type
Swivel
Shipping Weight
.8 lb.
Caster Temperature Range
-40 deg. F to 175 deg. F
Stem Diameter
3/8 in.
Caster Temperature Range Available
Yes
Stem Length
1-1/2 in.
Caster Thread Size
3/8-16
Stem Type
Threaded
Caster Wheel Bearings
Plain
Wheel Bearings
Plain
Caster Wheel/Tread Material
Polyurethane
Wheel Color
Gray
Core Color
Black
Wheel Diameter
4 in.
Core Material
Polyolefin
Wheel Material
Polyurethane
Frame Finish
Zinc Plated
Wheel Width
1 in.
Item
Stem Caster
General
Application
Fixtures, Institutional Equipment, Medical Equipment, Equipment Carts, Furniture
Standards
ANSI/ICWM
Brake Type
No Brake Included
Stem Dia.
3/8 in
Caster Frame Material
Steel
Swivel Raceway Type
Double Ball
Caster Product Group
Swivel Caster
Tread Shape
Standard
Caster Stem Size
3/8"-16 x 1-1/2 in
Wheel Bearing
Plain Bore
Caster Temp. Range Available
Yes
Wheel Bearing Type
Plain
Load Rating Range
0 to 299 lb
Wheel Core Material
Plastic
Operating Temperature Range
-40° to 175°F
Wheel Dia.
4 in
Raceway
Double Ball
Wheel/Tread Material
Polyurethane

Product Description

General purpose threaded stem casters are used on carts, furniture, storage cabinets, storage bins, display stands, appliances, retail fixtures, and other equipment in a wide variety of institutional and industrial settings. They have double ball swivel bearings that allow the caster to swivel smoothly.

Threaded stem casters are the most commonly used type of stem caster. They have a threaded stem on top that screws into a threaded hole, bracket, insert, or socket on a piece of equipment. The casters allow the equipment to roll, which reduces the effort it takes to move or reposition the equipment. Threaded stem casters are typically used to add casters on equipment where there is not enough room on the equipment's mounting surface to attach a plate caster's mounting plate.
