Schneider Electric 24VAC Coil Volts, General Purpose Relay, 15A @ 120V, 12A @ 277VAC/12A @ 28VDC Contact Rating, Square

Hover over image to magnify
Plug In Relay,11 Pins,Square,
Plug In Relay,11 Pins,Square,
Schneider Electric 24VAC Coil Volts, General Purpose Relay, 15A @ 120V, 12A @ 277VAC/12A @ 28VDC Contact Rating, Square Video

#927084-6 | Pkg Qty: 1

$21.74 pkg | $21.74 ea

Technical Specifications

Key Specifications
AC Contact Rating
15 A @ 120 V, 12 A @ 277 V
Mounting
Plug In
Base Type
Square
Number of Contacts
3
Body Depth
1.1 in.
Number of Pins
11
Body Height
1.6 in.
Number of Poles
3
Body Width
1.2 in.
Overall Height
1.85 in.
Brand
SCHNEIDER ELECTRIC
Pack Quantity
1
Coil VA Rating
1-1/2
Pins
11
Coil Volts
24 VAC
Plug-In Relay Style
General Purpose
Contact Form
3PDT
Push To Test
Lockable
Contact Material
Silver Alloy
Relay Power Consumption
1.5 VA
Contact Rating
15 A @ 120 VAC, 12 A @ 277 VAC/28 VDC
Resistive Contact Amp Rating
15
DC Contact Rating
12 A @ 28 V
Response Time
20 msec
HP @ 120 V
2022-01-02
Shipping Weight
.19 lb.
HP @ 240 V
2022-03-04
Socket
Mfr. No. 70-783D11-1A
Hz
50/60
Socket Code
E
Input Power Consumption
1.5 VA
Status Indicator
LED and Mechanical Flag
Item
General Purpose Relay
Type
Plug-In
Mfr. Part Number
783XCXM4L-24A
General
AC Contact Rating - Relay
12A @ 277V, 15A @ 120V
HP @ 120V
1/2 hp
Base Type - Plug In Relay
Square
HP @ 240V
3/4 hp
Body Depth - Relay
1.1 in
Mounting - Relay
Plug In
Body Height - Relay
1.6 in
Number of Pins - Relay
11
Body Width - Relay
1.2 in
Overall Height - Relay
1.85 in
Contact Form - Relay
3PDT
Power Consumption - Relay
1.5 VA
DC Contact Rating - Relay
12A @ 28V
Socket Code - Relay
E
Features
Gold Flashed Contacts
Standards
CSA Certified, CE Marked

Product Description

General Purpose Relay, Coil Volts 24V AC, AC Contact Rating - Relay 12A @ 277V, 15A @ 120V, DC Contact Rating - Relay 12A @ 28V, Base Type - Plug In Relay Square, Number of Pins - Relay 11, Contact Form - Relay 3PDT, Mounting - Relay Plug In, Socket Code - Relay E, Power Consumption - Relay 1.5 VA, Contact Material Silver Alloy, Status Indicator LED and Mechanical Flag, Push To Test Lockable
