|Mfg Part Number||B7V3BB549A|
- Shipping Weight 2.555 lbs.
- Item Solenoid Air Control Valve
- Valve Ways and Positions 3-Way/2-Position
- Voltage 24VDC
- Valve Actuator / Return Solenoid / Spring
- Pipe Size 1/2"
- Max. CFM - Valves 5.90
- Operational Pressure Range 35 to 145 psi
- NEMA Classification NEMA 4
- Valve Vacuum Range 0 to 28" Hg
- Normally Open / Normally Closed Normally Closed
- Body Style Body Ported
- Pilot Port Size 1/2" NPT
- Coefficient of Volume 5.9
- Electrical Connections 15mm, 3-Pin Male DIN
- Ambient Temp. Range 5 Degrees to 120 Degrees F
- Override Non-Locking Flush
- Overall Height 3"
- Overall Length 8"
- Overall Width 1-1/2"
- Standards CE, CSA, cUS
- Pneumatic Valves Product Group Solenoid Air Control Valve
|VMRS (ATA) CODES||053-006-009||Solenoid Air Control,1/2",|
