TRITAN
Pillow Block Bearing, Number of Bolts: 2, Ball Bearing Type, 2-1/2" Bore Dia.
Hover over image to magnify
#926775-1Pkg Qty: 1
$210.13 pkg | $210.13 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Bearing Housing Material Type
Cast Iron
Mfr. Part Number
UCP213-40
Bearing Insert Material
52100 Chrome Steel
Number of Bolts
2
Bearing Insert Type
Ball
Overall Height
150 mm
Bearing Lubrication
Shell Alvania RL2 or NLGI #2 Equivalent
Overall Length
265 mm
Bolt Hole Center-to-Center
203 mm
Overall Width
65.1 mm
Bolt Size
3/4 in.
Package Quantity
1
Bore Diameter
2-1/2 in.
Series
UCP
Brand
TRITAN
Shaft Locking Type
Set Screw
Dimension E
2-11/16 in.
Shipping Weight
13.2 lb.
Dynamic Load Capacity
12,927 lb.
Static Load Capacity
8992 lb.
Finish
Painted
Temperature Range
-40 deg. F to 250 deg. F
Item
Pillow Block Bearing
General
Standards
AFBMA, ISO
Product Description
Pillow Block Bearing, Ball Bearing Insert Type, 2 1/2 in Bore Dia., Bolt Hole Center-to-Center 203 mm, Mounting Surface to Shaft Center 76.2 mm, Cast Iron Bearing Housing Material Type, Set Screw Shaft Locking Type, 52100 Chrome Steel Bearing Insert Material, UCP Series, Number of Bolts 2, Bolt Size 3/4 in, Overall Height 150 mm, Overall Width 65.1 mm, Overall Length 265 mm, Bearing Lubrication Shell Alvania RL2 or NLGI #2 Equivalent, Dynamic Load Capacity 12,927 lb
Item Barcode
Pillow Block Bearing,Ball,2-1/
