Mobile Manual Lift, Manual Push Scissor Lift Table, 400 lb. Load Capacity, Lifting Height Max. 29

Hover over image to magnify
Scissor Lift Cart,400 Lb.,SS,
PI_Asset_969516
PI_Asset_969517
PI_Asset_969518
Scissor Lift Cart,400 Lb.,SS,
PI_Asset_969516
PI_Asset_969517
PI_Asset_969518

#926008-6 | Pkg Qty: 1

$1,867.16 pkg | $1,867.16 ea
Pricing is subject to change without notice

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Brand
APPROVED SUPPLIER
Load Capacity
400 lb.
Caster Diameter
4 in.
Lowered Height
8-3/4 in.
Caster Material
Poly-on-Poly
Mfr. Part Number
CART-400-PSS
Caster Type
(2) Rigid, (2) Swivel with Brake
Mobile/Stationary
Mobile
Caster Wheel Diameter
4 in.
Overall Height
34-3/8 in.
Caster Wheel Type
(2) Rigid, (2) Swivel with Brake
Overall Length
36-3/4 in.
Frame Material
Stainless Steel
Overall Width
17-5/8 in.
Item
Scissor Lift Table
Package Quantity
1
Lift Control
Foot Pump
Phase
1
Lift Mechanism
Hydraulic
Platform Style
Fixed
Lift Mobility
Manual Lift, Manual Push
Platform Width
17-5/8 in.
Lift Table Item
Scissor Lift Table
Powered By
Foot Pump
Lift Table Platform Style
Fixed
Raised Height
29 in.
Lifting Height Maximum
29 in.
Shipping Weight
94.9 lb.
Lifting Height Minimum
8-3/4 in.
Type
Manual, Stainless Steel
General
Brake Type
Face Contact Brake
Lifting Height per Pump
1 1/2 in
Caster Dia.
4 in
Overall LxWxH
36 3/4 in x 17 1/2 in x 34 3/8 in
Caster Wheel Dia.
4 in
Platform LxW
27 1/2 in x 17 1/2 in
Elevation per Stroke
1-1/2"
Platform Type
Solid
Foot Pump
Single Speed
Scissor Type
Single
Includes
Hydraulic Foot Pump
Up Speed Seconds
29 sec
Lifting Height Max.
29 in
Wheel Configuration
(2) Swivel with Brake, (2) Rigid
Lifting Height Min.
8 3/4 in
Wheel/Tread Material
Polyurethane

Product Description

Corrosion-resistant manual mobile scissor-lift tables are made from stainless steel or a combination of steel and stainless steel. They resist rusting when exposed to high humidity, moisture, frequent cleaning, and chemicals. The tables have a scissor-style support frame that allows their platform to be raised or lowered to a wider range of heights than post-lift tables. The platform sits close to the ground when fully lowered, so heavy items don't need to be lifted far during loading and unloading. The tables have a hydraulic lifting mechanism that is controlled with a foot pump, and their wheels have polyurethane treads that resist exposure to chemicals and moisture and won't mark floors.
