IEC Supplementary Protector, 16 Amps, Number of Poles: 3, 277/480VAC AC Voltage Rating

IEC Supplementary Protector, 16 Amps, Number of Poles: 3, 277/480VAC AC Voltage Rating

#925982-2 | Pkg Qty: 1

$295.13 pkg | $295.13 ea
Item Number 925982-2
Scanner Description Supp Protectr,16A,3P,C,277/
Inventory Status Drop Ship Item
Weight 0.77 lb
Brand SCHNEIDER ELECTRIC

Technical Specifications

AC Voltage Rating
277/480VAC
Item
IEC Supplementary Protector
AIR @ 277VAC
5kA
Length
3.19 in.
AIR @ 48VDC
10kA
Low Amp Trip Setting
112
Air @ 120VAC
10kA
Maximum Air Rating
5 kA
Air @ 125VDC
10kA
Maximum Wire Size
4 AWG
Air @ 240VAC
10kA
Mfr. Part Number
MG24468
Air @ 480VAC
5.0kA
Minimum Wire Size
14 AWG
Air @ 65VDC
10kA
Mounting
DIN Rail
Amperage
16
Number of Poles
3
Amps
16
Pack Quantity
1
Brand
SCHNEIDER ELECTRIC
Phase
3
Circuit Breaker Type
Miniature UL 1077
Series
C60N
Curve Type
C
Standards
UL 1077, CE, CSA, IEC
DC Voltage Rating
125VDC
Terminal Connection
Lug
Depth
3 in.
Trip Type
Thermal Magnetic
Frame Size
63A/C100N
Type
Din Rail Mount
High Amp Trip Setting
160
Voltage
480Y - 277 VAC
Instantaneous Trip
Fixed
Width
2.14 in.

Product Description

Miniature Circuit Protectors and Breakers

  • B curve = magnetic trip between 3.2 and 4.8 times rated current (computer, electronic, and generator applications) C curve = magnetic trip between 7 and 10 times rated current AC and 7 to 14 times for DC (general purpose applications) D curve = magnetic trip between 10 and 14 times rated current (motors, transformers, and similar applications)
  • Multi 9 breakers feature factory-calibrated overload curves. Withstand 6000V impulse. Rated for 20,000 tripping operation cycles. Line and load side box lug terminals (pressure plate type) are suitable for use with multiple wires. DIN rail or panel mount with accessory front bracket. Wire size: max. 4 AWG Cu for 0.5 to 25A models, max. 2 AWG Cu for 30 to 63A models.
  • UL 1077 Supplementary Protection within Equipment
  • 10kA IR at 240VAC 5kA IR at 480Y/277VAC
  • Must use with circuit breaker or fuse. Recognized components for applications permitting supplementary protectors. Not a substitute for UL 489 models, and must be used in conjunction with branch circuit protection when connecting to external devices.
  • UL 1077 Supplementary Protection within Equipment
  • 10kA IR at 240VAC 5kA IR at 480Y/277VAC
  • Must use with circuit breaker or fuse. Recognized components for applications permitting supplementary protectors. Not a substitute for UL 489 models, and must be used in conjunction with branch circuit protection when connecting to external devices.
