Circuit Breaker, 250 Amps, Number of Poles: 2, 240VAC AC Voltage Rating

Circuit Breaker, 250 Amps, Number of Poles: 2, 240VAC AC Voltage Rating

#925484-1 | Pkg Qty: 1

$1,246.44 pkg | $1,246.44 ea
Item Number 925484-1
Scanner Description Circuit Breaker,250A,2P,240VAC,
Inventory Status Drop Ship Item
Weight 3.4 lb
Brand SQUARE D

Technical Specifications

AC Voltage Rating
240VAC
Item
Circuit Breaker
AIR @ 277VAC
Not Rated
Length
6.47 in.
AIR @ 48VDC
Not Rated
Low Amp Trip Setting
1200A
Air @ 120VAC
Not Rated
Maximum Air Rating
25 kA
Air @ 125VDC
Not Rated
Maximum Wire Size
300 kcmil
Air @ 240VAC
25kA
Mfr. Part Number
QDL22250
Air @ 480VAC
Not Rated
Minimum Wire Size
4 AWG
Air @ 600VAC
Not Rated
Mounting
Free Standing
Air @ 65VDC
Not Rated
Number of Poles
2
Amperage
250
Pack Quantity
1
Amps
250
Phase
1
Brand
SQUARE D
Series
QD
Circuit Breaker Type
Standard
Standards
UL Listed, CSA Certified, CE Marked, IEC
DC Voltage Rating
Not Rated
Terminal Connection
Lug
Depth
3.93 in.
Trip Type
Thermal Magnetic
Frame Size
250A/QD
Type
Free Standing
Height
6.47 in.
Voltage
240 VAC
High Amp Trip Setting
2400A
Warranty
2ACD2
Instantaneous Trip
Fixed
Width
3 in.

Product Description

QOU, QDL, and QBL Circuit Breakers

  • QDL
  • 250A Q-frame. 2-pole models are 6.47"L x 3"W x 3.93"D; 3-pole models are 6.47"L x 4.5"W x 3.93"D.
Item Barcode
9254841
  Name Item Description
Grainger Dropship Grainger Dropship 2JXC3 Circuit Breaker,250A,
UNSPSC CODES UNSPSC CODES 39121601
VMRS (ATA) CODES VMRS (ATA) CODES 053-006-009 Circuit Breaker,250A,
