120VAC, 8-Pin Surface Open Power Relay; Electrical Connection: Screw

120VAC, 8-Pin Surface Open Power Relay; Electrical Connection: Screw
Open Power Relay,8 Pin,120VAC,
PI_Asset_1368458
120VAC, 8-Pin Surface Open Power Relay; Electrical Connection: Screw Video

#922718-8 | Pkg Qty: 1

$41.96 pkg | $41.96 ea
Item Number 922718-8
Scanner Description Open Power Relay,8 Pin,120VAC,
Inventory Status Drop Ship Item
Weight 0.65 lb
Brand DAYTON

Technical Specifications

AC Contact Rating
40A @ 300V
Input Power Consumption
10.0VA
Body Depth
3.4 in.
Item
Open Power Relay
Body Height
2-1/2 in.
Mfr. Part Number
5Z534
Body Width
2-1/2 in.
Mounting
Surface
Brand
DAYTON
Number of Pins
8
Coil Rating
Not Rated
Number of Poles
2
Coil Volts
120VAC
Overall Height
2-1/2 in.
Contact Form
DPDT
Pack Quantity
1
Contact Material
Silver Cadmium Oxide
Pins
8
Contact Rating
40A @ 300VAC/28VDC
Power Relay Style
Open Power Relay
DC Contact Rating
40A @ 28V
Relay Power Consumption
10.0VA
Dimensions
2.50 in.H, 2.50 in.W, 3.40 in.D
Resistive Contact Amp Rating
40A @ 300VAC/28VDC
Electrical Connection
Screw
Standards
E40944
Features
Magnetic Blowout
Type
Power, Open Style

Product Description

Heavy-Duty Power Relays

  • Screw-head terminals Silver alloy, self-wiping contacts Molded thermoset plastic base RoHS compliant
  • Use for switching motor loads in applications such as elevators, machine tools, air handling, and HVAC equipment. Minimum operating voltage for AC relays is 85% of nominal voltage (75% for Nos. 1EJJ8 and 1EJJ9). 0.75 power factor. Relays with magnetic blowout feature suppress arcing.
  • UL Listed, CSA Certified, and CE Certified.
Item Barcode
9227188
  Name Item Description
Grainger Dropship Grainger Dropship 5Z534 Open Power Relay,8 Pin,
UNSPSC CODES UNSPSC CODES 39121514
VMRS (ATA) CODES VMRS (ATA) CODES 053-006-009 Open Power Relay,8 Pin,

For more product information by email, click here
