IEC Supplementary Protector, 20 Amps, Number of Poles: 2, 277/480VAC AC Voltage Rating

IEC Supplementary Protector, 20 Amps, Number of Poles: 2, 277/480VAC AC Voltage Rating

#918189-8 | Pkg Qty: 1

$183.00 pkg | $183.00 ea
Item Number 918189-8
Scanner Description Suppl Protectr,20A,2P,D,277/
Inventory Status Drop Ship Item
Weight 0.35 lb
Brand EATON

Technical Specifications

AC Voltage Rating
277/480VAC
Low Amp Trip Setting
20
AIR @ 277VAC
5kA
Max. AIR Rating
5 kA
AIR @ 48VDC
5kA
Max. DC Voltage (V)
48/96VDC
Air @ 120VAC
5kA
Max. Wire Size
4 AWG
Air @ 125VDC
5kA
Mfr. Part Number
FAZ-D20/2
Air @ 240VAC
5kA
Min. Wire Size
18 AWG
Air @ 480VAC
5.0kA
Mounting
DIN Rail
Air @ 600VAC
5kA
Mounting Type
Din Rail
Air @ 65VDC
5kA
Number of Poles
2
Amperage (A)
20
Pack Quantity
1
Amps
20
Panelboard Mounting
Din Rail
Application
Motors, Transformers and Power Supplies
Phase
2
Brand
EATON
Phase Connection
Lug
Circuit Breaker Type
Miniature UL 1077
Series
FAZ
Curve Type
D
Standards
UL 1077, CSA C22.2 No. 235, RoHS, VDE, CCC, ABS Compliant
DC Voltage Rating
96VDC
Switch Type
Lever
Depth
72.6 mm
Terminal Connection
Lug
Frame Size
63A
Trip Type
Thermal Magnetic
High Amp Trip Setting
20
Type
DIN Rail Mount
Instantaneous Trip
Fixed
Voltage
277/480 VAC
Item
IEC Supplementary Protector
Width
36 mm
Length
84.7 mm

Product Description

IEC Supplementary Protector, Amps 20 A, AC Voltage Rating 277/480V AC, Max. AIR Rating 15kA at 240/415V AC, Series FAZ, Curve Type D, DC Voltage Rating 96V DC, Number of Poles 2, Phase 1, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style DIN Rail, Meets UL Type UL 1077, Terminal Connection Lug, Trip Type Thermal Magnetic

Item Barcode
9181898
  Name Item Description
Grainger Dropship Grainger Dropship 19YF35 Suppl Protectr,20A,
UNSPSC CODES UNSPSC CODES 39121601
VMRS (ATA) CODES VMRS (ATA) CODES 053-006-009 Suppl Protectr,20A,
