12VDC, 6-Pin Bottom Flange Enclosed Power Relay; Electrical Connection: Screw
#916352-2 | Pkg Qty: 1
$24.75 pkg
| $24.75 ea
| Item Number | 916352-2 |
| Scanner Description | Enclosed Power Relay,6 Pin, |
| Inventory Status | Drop Ship Item |
| Weight | 0.25 lb |
| Brand | OMRON |
Technical Specifications
AC Contact Rating
25A @ 240V
HP @ 120V
1
Base Type
Flange, Top Mount
HP @ 240V
3
Body Depth
1.36 in.
Hz
50/60
Body Height
1.99 in.
Input Power Consumption (Burden)
1.9W
Body Width
2.7 in.
Item
Enclosed Power Relay
Brand
OMRON
Mfr. Part Number
G7L-2A-BUBJ-CB-DC12
Coil Rating
2.5VA, 1.9W
Mounting
Bottom Flange
Coil VA Rating
1.9
Number of Pins
6
Coil Volts
12VDC
Number of Poles
2
Contact Amp Rating
25A @ 220VAC
Overall Height
2.52 in.
Contact Amp Rating (Inductive)
25A @ 220VAC
Pack Quantity
1
Contact Amp Rating (Resistive)
25A @ 277VAC
Pins
6
Contact Form
DPST-NO
Power Relay Style
Enclosed Power Relay
Contact Form - Relay
DPST-NO
Relay Power Consumption
1.9W
Contact Material
Silver Alloy
Response Time
30 msec
Contact Rating
30A @ 277VAC
Series
G7L
Dimensions
1.99 in.H, 2.70 in.W, 1.36 in.D
Standards
UL, CSA, TUV, Meets IEC950
Electrical Connection
Screw
Type
Power
Features
No Contact Chattering for Momentary Voltage Drops up to 50% of Rated Voltage, Flame-Resist
Product Description
Featuring top-mounted terminals, this enclosed power relay has a flange-type mounting bracket. Dielectric strength: 4000VAC at 1 min.
