HELICOIL

5/16"-18, Tap, Right Hand, Plug, 4 Flutes, High Speed Steel, Uncoated Tap Finish

Hover over image to magnify
Hand Tap,Plug,5/16 Inx18,
Hand Tap,Plug,5/16 Inx18,

#916043-5 | Pkg Qty: 1

$27.32 pkg | $27.32 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications
Brand
HELICOIL
Size
5/16 in.
Cutting Direction
Right
Spiral Direction
Neutral
Cutting Direction
Right Hand
Subgroup | Tap
Straight Flute
Finish
Uncoated
Tap Chamfer
Plug
Flutes
4
Tap Dimension Type
Inch
Item
Screw Thread Insert STI Tap
Tap Finish
Bright (Uncoated)
Material
High Speed Steel
Tap Material
High Speed Steel
Mfr. Part Number
5CPB
Tap Size
5/16 in.
Number of Flutes
4
Tap Style
Straight Flute (Hand)
Number of Pieces
1
Tap Thread Size
5/16 in.-18
Overall Length
2-15/16 in.
Tap Thread Type
UNC
Pack Quantity
1
Thread Direction
Right Hand
Pitch
18
Thread Length
1-1/4 in.
Pitch Diameter Limits
H3
Thread Type
UNC
Shank Diameter
3/8 in.
Tolerance
3B
Shipping Weight
.08 lb.
Type
Plug
General
55% Thread Drill Size
I
Shank Type - Machining
Straight
65% Thread Drill Size
17/64 in
Standards
ANSI, ISO 9001, OS 9000, ISO 14001
75% Thread Drill Size
F
Tap Grouping
Individual
Application
For Use With Free Running and Screw Locking Inserts
Thread Limit
H3
Extended Neck
Yes
Thread Limit / Class of Fit
H3
Features
The Sti Taps Supplied For Standard Thread Repair Look Like Conventional Taps And May Be Used With The Same Tap Handle As Conventional Taps
Thread Standard
UNC
Measurement System
Fractional Inch
Threads per Inch
18
Shank Dia.
3/8 in

Product Description

Screw Thread Insert Taps

  • STI taps are oversized from standard taps to allow for the wire insert once installed. High-speed, steel intermediate (plug) lead taps cut threads to a precise dimension.
