TRIPP LITE

Tripp Lite Datacom Surge Protector, 10 Outlets; 15 Amps; 8 ft. Cord Length; 120 VAC; Black

Hover over image to magnify
Surge,10 Outlets,8ft Cord,3345
PI_Asset_976495
PI_Asset_976496
PI_Asset_976497
PI_Asset_976498
PI_Asset_976499
Surge,10 Outlets,8ft Cord,3345
PI_Asset_976495
PI_Asset_976496
PI_Asset_976497
PI_Asset_976498
PI_Asset_976499

#912783-2 | Pkg Qty: 1

$72.53 pkg | $72.53 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Brand
TRIPP LITE
NEC Cord Designation
SJT
Circuit Breaker
1
NEMA Plug Configuration
5-15P
Coax Surge Protection
Yes
NEMA Receptacle Configuration
5-15R
Color Family
Black
Noise Attenuation
Up to 40dB
Communication Port
(2) Coaxial, (3) RJ11 Telephone
Number of Conductors
3
Cord Length
8 ft.
Number of Total Outlets
10
Height
2-1/4 in.
Number of Transformer Outlets
4
Housing Material
Plastic
Outlet Center Distance
28.4 mm Standard; 56.8 mm Standard and Transformer
Hz
50/60 Hz
Outlet Surge Protection
Yes
Item
Surge Protector Outlet Strip
Package Quantity
1
Length
11-5/8 in.
Power Indicator
Yes
Maximum Amps
15 A
Power Strip Application
Home and Office
Maximum Surge Current
13.5kA
Rated Joules
3330
Medical Facility Use
Outside Patient Care Areas (UL 1363)
Shipping Weight
2.75 lb.
Medical Grade
No
Voltage
120 VAC
Mfr. Part Number
TLP1008TELTV
Width
5 in.
Mounting Style
Multiple Keyhole
Wire Size
14 AWG
General
Application
Home and Office
Noise Reduction Rating NRR
Up to 40dB
Cord Length - Ext. Cords and Outlet Strips
8 ft.
Number of Total Outlets - Ext. Cords and Outlet Strips
10
For Use With
Protecting TVs, DVDs, Satellites, Stereos and Other Entertainment Systems
Receptacle Configuration
NEMA 5-15R
Gauge/Conductor - Ext. Cords and Outlet Strips
14/3
Standards
UL1449/1363/497A/cUL/FCC Part68/Industry Canada, Approvals RoHS
Includes
6 ft gold coax Cable, 6 ft RJ11 Cable, Instruction Manual and Warranty Information
Total Number of Outlets
10
Max. Amps - Ext. Cords and Outlet Strips
15.0
Trade Designation
SJT
NEMA Plug Configuration - Ext. Cords and Outlet Strips
5-15P

Product Description

Datacom surge-protected power strips supply power to multiple devices from one outlet while preventing voltage spikes from damaging sensitive electronics. Also known as surge suppressors, these blocks include both standard outlets and ports for data cables, such as USB, coaxial, or telephone cables. They are typically used in office and commercial settings to power computer systems and hardware, modems, fax machines, and phones.

Surge-protected power strips are portable blocks of electrical sockets that supply power to multiple devices from one outlet and protect the connected devices from damage due to unexpected voltage increases. Also called a surge suppressor, the surge protector absorbs the excess voltage and diverts it to the ground wire, preventing it from reaching the connected equipment. A surge protector's joule rating determines how much energy it can absorb before it fails. A higher number indicates greater protection. These outlet strips are typically used to provide additional outlets in areas that don't have enough wall receptacles for the number of devices. They are portable and can be unplugged and moved to another location as needed. They are suitable for homes, offices, medical facilities, and industrial environments where protection from power spikes is a priority.
