Circuit Breaker, Thermal Circuit Breaker Type, Push Button Switch Type, Number of Poles: 1

Circuit Breaker, Thermal Circuit Breaker Type, Push Button Switch Type, Number of Poles: 1
Breaker,Circuit,20 Amp
PI_Asset_1369987

#912108-5 | Pkg Qty: 1

$2.51 pkg | $2.51 ea
Item Number 912108-5
Scanner Description Breaker,Circuit,20 Amp
Inventory Status Drop Ship Item
Weight 0.06 lb
Brand CARLING TECHNOLOGIES

Technical Specifications

AC Voltage Rating
250VAC
Maximum Air Rating
Not Rated
Air @ 120 VAC
Not Rated
Maximum DC Voltage
32
Air @ 125 VDC
Not Rated
Maximum Wire Size
12 AWG
Air @ 240 VAC
0.2KA
Mfr. Part Number
CLB-203-27E3N-W-A/20
Air @ 277 VAC
Not Rated
Mounting Type
3/8 in. Collar
Air @ 65 VDC
Not Rated
Number of Poles
1
Amperage
20
Pack Quantity
1
Amps
20
Phase
1
Brand
CARLING TECHNOLOGIES
Standards
UL/cUL/CSA/TUV/CE/UL 1500/ISO8846 for Ignition Protection/Marine
Circuit Breaker Type
Thermal
Switch Type
Push Button
Curve Type
Medium
Terminal Connection
1/4 in. Tab
DC Voltage Rating
32VDC
Type
Collar Mount
Depth
2.31 in.
Voltage
250
Item
Circuit Breaker
Width
0.57 in.
Length
1.38 in.

Product Description

Panel-Mount Circuit Breakers

  • Thermal Trip
  • Operating temp.: -10° to 60°C Functionally equal: ETA, Joemex, and MPI
  • Compact, precision-design breakers have few moving parts a cost-effective alternative to hydraulic/magnetic breakers. They offer extremely reliable circuit protection with high resistance against shock and vibration. Half-shell construction. 50/60 Hz. UL Listed.
Item Barcode
9121085
  Name Item Description
Grainger Dropship Grainger Dropship 4VA77 Breaker, Circuit,20
UNSPSC CODES UNSPSC CODES 39121601
VMRS (ATA) CODES VMRS (ATA) CODES 034-004-010 Breaker, Circuit,20
