HALDEX

Haldex 3030 Gold Seal Combination Spring Brake - GC3030

Hover over image to magnify
Haldex Combo Ab Act 3030 Std
Haldex Combo Ab Act 3030 Std
Haldex 3030 Gold Seal Combination Spring Brake - GC3030 Video
Haldex 3030 Gold Seal Combination Spring Brake - GC3030 Video

#91702 | Pkg Qty: 1

$79.89 pkg | $79.89 ea

In Stock

Shipping to 60045
Catalog: G27

Technical Specifications

Air Port Thread
3/8-18 NPTF
Pushrod Thread
5/8-18 UNF
Available Stroke
2-1/2 in.
Shipping Weight
17 lb.
Brand
HALDEX
Stud Grade
5
Item
Spring Brake
Stud Length
1-1/2 in.
Maximum Air Pressure
150 psi
Stud Spacing
4-3/4 in.
Mfr. Part Number
GC3030
Stud Type
5/8-11 UNC
Pack Quantity
1

Product Description

Haldexx® Gold Seal Air Brake Actuator
  • Combination Actuator - 3030 Standard Stroke
  • Superior Power Spring Technology: Advanced Powder Coating For Corrosion Restistance
  • Double O-Ring Centerseal: Positive Sealing And Plastic Bearings For Long Life
  • Superior Diaphragm: High Quality Rubber Compound Resists Heat And Cold, Flexible Even At -40°F
  • Rugged Service Housing: 9 Gauge Powder Coated Steel
  • Maximum Air Pressure: 150 Psi
Item Barcode
0917020
Haldex Combo Ab Act 3030 Std
 NameItemDescription
UNSPSC CODESUNSPSC CODES25171700
VMRS (ATA) CODESVMRS (ATA) CODES013-004-027COMBO AB ACT 3030 STNRD
