Technical Specifications
Brand
METRI-PACK
Pack Quantity
10
Item
Double Position Assurance
Series
280
Mfr. Part Number
280TPA-2
Temperature Range (Deg. C)
-40 to +125 deg. C
Product Description
Metri-Pack 280 Series Terminal
- Metri-Pack 280 Delphi Connectors. These In-Line Delphi Connectors Feature High Current And Current Density In A Small, Compact Design. Because Of Their Excellent Resistance To Temperature, Chemicals, And Abrasions, 280 Series Delphi Connectors May Be Used In Under-Hood Automotive Applications As Well As Most Marine, Off-Road, And Agricultural Applications. Rated For 16 Volts And 30 Amps, Delphi Connectors Must Be Used In Conjunction With A Sealed Splice Pack System.
- Uses Triple-Rib Peripherial Silicone Rubber Seals, Making Them Ideally Suited For Critical, Low-Energy Electronic Applications That Require Protection From Environental Hazards.
- Low Energy, Low Voltage.
- Excellent Resistance To Temperature, Chemicals, And Abrasion.
- Temperature Range: -40° C. To 125° C.
- Continuous Maximum Current Rating: 30 Amps.
- Terminal Position Assurance Compatible With:
- Part No. 74008 , Double Female Housings
- Part No. 74009 , Double Male Housings
- Part No. 74002 , Gray Cable Seal, For 16-14 Gauge Wire
- Part No. 74003 , Blue Cable Seal, For 12 Gauge Wire.
- To Disassemble, Use Metri-Pack Release Tool, Part No. 74048 .
- Cross Reference: 15300014
Item Barcode
Term Position Assurance Double
| Name | Item | Description | |
|---|---|---|---|
|
UNSPSC CODES | 39121700 | TERMINAL POS ASSURANCE |
|
VMRS (ATA) CODES | 052-007-002 | TERMINAL POS ASSURANCE |
