100 ft. Cross-Link Primary Wire with 1 Conductor(s), 18 AWG, 50 V, Yellow

Hover over image to magnify
18 Ga Yellow Cross Link
PI_Asset_1081423
18 Ga Yellow Cross Link
PI_Asset_1081423

#71994-1 | Pkg Qty: 100

Color Family : Yellow
Black
Blue
Brown
Green
Red
White
Yellow

In Stock

Shipping to 60045
|
Catalog: E31

Technical Specifications

Key Specifications
Brand
APPROVED SUPPLIER
Mfr. Part Number
71994-1
Color Family
Yellow
Number of Conductors
1
Electrical Wire Type
Cross-Link Primary Wire
Package Quantity
100
Insulation Material
SXL
Shipping Weight
1 lb.
Item
Electrical Wire
Voltage
50 V
Length
100 ft.
Wire Gauge
18 AWG
General
Features
Fire Resistant, Flexible at Extreme Low Temps.

Product Description

Sxl Cross-Link Primary Wire
  • Cross-Link Is Quickly Becoming The Most Commonly Used Wire On The Market!
  • Noted Superior To Any Other Primary Wire In Pinch, Abrasion, And Heat Aging Test.
  • Superior Resistance To Elements, Abrasion, And Where Temperature Extremes Are Encountered.
  • Meets SAE J1128 Specifications.
  • Compatible With Ford M1L-85A And Chrysler Ms-5919.
  • Stranded Annealed Soft Copper.
  • Primary Applications: Trucks, Tractors And Car Engine Compartment Where Higher Heat Resistance Is Required.
  • Temperature Rating: -59° F To 257° F (-51° C To 125° C)
  • Voltage Range: 50 Volts Maximum
  • Wire Gauge: 18
  • Color: Yellow
  • Quantity: One 100 Foot Roll
