LOCTITE
Loctite Threadlocker: Series 262, Threadlocker, Red, Liquid, 250 mL, Bottle
Hover over image to magnify
#914398-7 | Pkg Qty: 1
$235.56 pkg | $235.56 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Appearance
Red
Package Quantity
1
Begins to Harden
10 min.
Performance Temperature Range
-65 deg. F to 300 deg. F
Brand
LOCTITE
Physical Form
Liquid
Chemical Type
Anaerobic
Removable With
Heat and Hand Tools
Color Family
Red
Series
262
Fills
Gaps Between Threads
Shipping Weight
.75 lb.
Fixture Time
10 min.
Size
250 mL
Flash Point
200 deg. F
Specific Gravity
1.05
For Fastener Diameter
Up to 3/4 in.
Temperature Range
-65 to 300 deg. F
Full Cure
24 hr.
Threadlocker Classification
Threadlocker
Full Cure Time
1 day
Threadlocker Disassembly
Permanent
Gap Fill
0.005 in.
Threadlocker Strength
High Strength
Item
High-Strength Threadlocker
Type
High Strength Threadlocker
Mfr. Part Number
135375
Viscosity
1,800 to 5,000 cP
Net Weight
250 mL
General
Application
Locking Bolts Up to 3/4 in. For Extreme Environmental, Chemical Conditions, Heavy Shock and Vibration Applications. High Strength Requires Heat and/or Special Tools For Removal
Minimum Viscosity
1,200 cps
Breakaway Torque
190 in-lb
Mixing Required
No
Breakaway Torque Range
101 in-lb to 200 in-lb
Pack Size
1 EA
Clean Up Method
Solvent, Wire Brush
Prevailing Torque
350 in-lb
Compatible Materials
Bronze, Copper, Iron, Manganese, Nickel, Steel
Product Form
Liquid
Compatible Primer ( Part Number)
4KL11
Recommended Surface Preparation
Dry Surface
Compatible Primer Series
Loctite 7649
Removal Method
Hand Tool and Heat
Container Size Range
Over 1.1 oz
Standards
MIL-S-46163A Type II Grade 0, OSHA Hazard Communication, RoHS Compliant
Container Size and Type
8.45 fl oz Bottle
Storage Requirements
8 Degrees to 21 Degrees C
Container and Size
Bottle Over 1.1 oz
Threadlocker Properties
Oil Tolerant
Cure Type
Anaerobic
Torque and Strength
190 in-lb High
For Material Type
Brass, Bronze, Copper, Iron, Manganese, Monel, Nickel, Steel
Working Time
8 min
For Maximum Thread Diameter
3/4 in
Working Time Range
6 min to 10 min
Product Description
Specialty Threadlockers
- Fill gaps between threads and securely mate surfaces to form solid, unitized assemblies. Prevent fasteners from loosening due to vibration and protect against rust and corrosion
- Permanent
- For extreme environmental, chemical, heavy shock, and vibration applications. Solvents will not weaken the adhesive bond. Withstands temperatures up to 300°F.
- Threadlockers
- Fill gaps between threads to help form solid, unitized assemblies. Prevent fasteners from loosening due to vibration and protect against rust and corrosion
- High-Strength
- Fasteners can be removed with hand tools after heat is applied.
